Pigeon Flying Ability Appraisal Instrument HM-P32

Introduction:

For a long time, having a good bloodline has been considered an important factor affecting competition performance, and the so-called good bloodline refers to specific heritable genotypes. Given that certain genes in racing pigeons have a significant impact on their athletic ability, through reference to authoritative literature and European testing experience, combined with existing innovative technologies, it has been found that homing ability indicators, endurance indicators, cryptochrome indicators, muscle growth inhibition indicators, feather keratin indicators, intelligence, and rainy weather orientation have important reference roles in breeding pigeon flight ability. By testing the above indicators, a more scientific reference basis can be provided for pigeon enthusiasts in the process of selecting racing pigeons and breeding pigeons.

Our pigeon flight ability identification device, developed based on the aforementioned genetic research, can simultaneously identify genes that affect flight ability, including pigeon gender and homing ability DRD4, flight endurance LDHA, navigation ability, circadian rhythm CRY1, muscle strength (muscle regulation) MSTN, wing (feather structure and strength) F-KER, intelligence CASK, and rainy day directional GSR.

Basic structure of the instrument:

The real-time fluorescence quantitative PCR system is an instrument for real-time detection of reactions, mainly composed of a gene amplification thermal cycle system, a fluorescence real-time detection system, a microcircuit control system, a computer, and application software. Two core functional modules are: thermal cycling system and real-time fluorescence detection system. The working principle of the gene amplification thermal cycle system is basically the same as that of traditional gene amplification instruments, using semiconductor heating and cooling to complete the thermal cycle process. The fluorescence detection system mainly consists of fluorescence excitation components, optical signal transmission components, fluorescence detection components, and control systems.

Instrument features:

1. Small size, light weight, easy to carry, compatible with 0.2PCR single tube and eight tube;

2. Adopting the American MARLOW customized Peltier module high-level semiconductor chip and the new generation of semiconductor temperature rise and fall technology, the fastest temperature change rate can reach 7 degrees per second, and the service life can reach one million cycles;

3. Adopting unique lighting detection and processing technology, automatically adjusting the fluorescence background, improving the sensitivity and signal-to-noise ratio of fluorescence signals, and obtaining better results;

4. 13S four channel fast lighting, stable fluorescence acquisition signal, reducing delay error;

5. Adopting maintenance free long-life LED light source, no need for replacement, independent fluorescent channel, and less crosstalk between different channels;

6. Constant current control circuit, smooth power output, extended Peltier life, and improved temperature control accuracy;

7. It has protection functions such as overcurrent and over temperature;

8. Powerful software analysis capabilities, including quantitative analysis, melting curve analysis, gene typing, etc. The analysis software is free to upgrade for life and supports software customization for different industries;

9. Comes with a 10 inch color touch screen control.

Technical parameters:

Dimensions: 235mm * 385mm * 175mm (width * depth * height)

Weight: 5.8Kg

Electrical parameters:~220V/50Hz, 255W

Data interface: USB 2.0 * 2

Operating conditions: Temperature: 10-30 ℃, Humidity: 20%~80%

Transportation and storage conditions: temperature: -20~55 ℃, humidity: 20%~80%

Altitude:<2500 meters

Noise level: A-weighted,<60dB

Sample size: 32 * 0.2mL

Test tube type: 0.2PCR single tube, eight row tube

Sample volume: 15-100uL

Heating/cooling method: semiconductor heating/cooling

Temperature range: 4 ℃ -99 ℃

Maximum heating rate: ≤ 5.5 ℃/s (MAX)

Average heating rate: ≥ 3.5 ℃/s

Maximum cooling rate: ≤ 4.5 ℃/s (MAX)

Average cooling rate: ≥ 2.5 ℃/s

Temperature control accuracy: ≤± 0.01 ℃

Temperature accuracy: ≤± 0.1 ℃

Temperature uniformity: ≤± 0.3 ℃

Number of fluorescence detection channels: 4 channels

Light emitting device: high brightness LED

Lighting device: high sensitivity, high signal-to-noise ratio photodiode

Compatible probe or dye: First channel: 470/520 FAM, SYBR Green

Second channel: 530/570 HEX, JOE, VIC

Third channel: 580/610 ROX, CY3.5, Texas Red

Fourth channel: 630/670 CY5

Detection sensitivity: 1 copy

Linear detection range: 100-1010 copies

Linear correlation coefficient: ≥ 0.999

Channel crosstalk: no crosstalk

Detection repeatability: ≤ 1.0%
